Only one safe can be the best. Champion’s Crown Series has won its title for being the crowning achievement in safe manufacturing. The Crown is the perfect synthesis of strength, fire protection, precision, and elegance. The Crown’s thick 7-Gauge body with the 5-1/2″ thick Double-Step™ door work together with sophisticated door defense systems to create the ultimate standard in security. The precision radial gear–driven boltworks possess unsurpassed strength and smoothness. The Crown’s 1750°F two-hour fire rating is one of the best in the industry. The plush velour interior features LED lighting and a custom door organizer for convenience. Four two-tone and five high-gloss mirror finishes add a final touch of class. Only one safe can be the best—it’s the Crown.
-
-
Fire and Security Ratings
- 1750°F Two-Hour Fire Rating
- Phoenix™ Class V Fire Protection
- Tested in an ASME Certi?ed Facility
- UL® Security Rating
- Lifetime Warranty
Locking System
- Sargent & Greenleaf® Group II Dial Lock
- Glass-Guard™ Relock System with Remote Relockers
- Champion’s Auto-Relock™ System
- Diamond-Embedded Armor Plate™
Boltworks
- Radial Gear–Driven Boltworks
- Four-Way Active Boltworks
- Up to 20, 1-1/2″- Diameter Door Bolts
- Bolt-Detent™ System
- Roughneck™ Bolt Guides
-
Interior
- Plush Velour Interior
- LED Lighting with Motion Sensor
- 110-Volt Power Receptacle
- Deluxe Door Organizer
See Interior Configurations Below
Maximum Security Door
- Exclusive Five-Inch Thick Delta Force™ Door
- 1/2″ Reinforced Door Edge
- 1/4″ Outer Door Steel, Full 10-Gauge Inner
- Three Layers of Fire Insulation
- Internal Ball-Bearing Hinges
- Five-Spoke Custom Handle with Slip Clutch
Body
- Classic Steel Arch Doorway™
- Up to 2-3/4″-Thick Composite Walls
- 7-Gauge Steel Walls
- Four Layers of Fire Insulation
- Double-Steel Door Casement™
- Dual Fire Seals
Locks
Standard Dial Optional E-Lock
Exterior/Interior Color Selections
Sizes and Dimensions
| Safe Model | Exterior Dimensions | Volume (Cubic Ft.) | Approx. Weight (lbs.) | Outer Shell Thickness | Outer Door Thickness | Inner Door Thickness | Active Door Bolts | Gun Capacity | |||
| Width | Height | Depth | Total Depth* | ||||||||
| CR-60 | 48" | 72.5" | 28" | 30.5" | 56 CF | 1730 | 7 ga. | 1/4" | 10 ga. | 20 - 1-1/2" | 64 |
| CR-50 | 42" | 72.5" | 28" | 30.5" | 50 CF | 1560 | 7 ga. | 1/4" | 10 ga. | 18 - 1-1/2" | 52 |
| CR-40 | 36" | 66.5" | 26" | 28.5" | 38 CF | 1200 | 7 ga. | 1/4" | 10 ga. | 16 - 1-1/2" | 43 |
| CR-30 | 30" | 66.5" | 24" | 26.5" | 30 CF | 1070 | 7 ga. | 1/4" | 10 ga. | 16 - 1-1/2" | 36 |
| *Total Depth includes 2½" for handle. |
Interior Layouts
